OEM Part Number |
HD34-24-21PE |
|
OEM Series |
HD30 CONNECTOR |
|
MinMax Part Number |
1150001199 |
|
Connection Type |
Wire to Wire, Wire to Board |
|
Number of Positions |
21 |
|
Number of Rows |
1 |
|
Hybrid |
Yes |
|
Contact Tab Size (mm) |
1.6 | 2.4 |
|
Male/Female |
Male |
|
Sealable |
Yes |
|
Body Color |
Gray |
|
Housing Material |
Shell: Aluminum Plastic inner core: Flame-retardant nylon Ring plug: Silicone |
|
Nominal Voltage Architecture (V) |
12 | 24 |
|
Operating Temperature Range |
-55 – 125 °C |
|
Certification |
ISO9001, RoHS, REACH, TS16949 |
DEUTSCH HD30 series are medium to heavy-duty connectors.They feature a sturdy metal shell, reliable sealing, and can handle complex environments like dust,moisture,and vibration. With multiple pin configurations, high current capacity, compatible with various wire gauges. Flexible installation (flange, in-line, etc.), stable and convenient connection (bayonet or threaded). Enhanced corrosion and high-temperature resistance, suitable for engineering machinery, heavy vehicles, etc.
✔Robust: Sturdy shell, sealed, resists dust, moisture, vibration, harsh environments.
✔Efficient: Multiple pins, bayonet/threaded, easy stable assembly/disassembly, high efficiency.
✔Adaptable: High current, fits multiple wires; flexible installation, widely applicable.
✔High-performance: Enhanced corrosion, high-temp resistance; suits high-demand fields.
On the Engine
On the transmission
Automotive Under the Hood
On the Chassis
In the Cab
in the heavy duty
EDM Mirror Processing
EDM Parts
Slow-feeding wire cut machine
CNC Machine
Plastic Injection Machine
Automatic production Line
Step 1 Crimp the terminal and do the pull-out test to make sure the crimpings are completed
step 2 Crimping terminal and matched connector
Step 3 Insert the terminal to the connectors
Step 4 finished the connecting.
