DTM04-12PA Male 12 Pins Sealed gray cable housing DTM Connector

OEM Part Number DTM04-12PA
OEM Series DTM
MinMax Part Number 1150000468
MinMax Family MCS049
Connection Type Wire to Wire
Number of Positions 012
Number of Rows 2
Hybrid No
Contact Tab Size (mm) 1.2mm
Male/Female Male
Sealable Yes
Body Color Gray
Housing Material PA66
Nominal Voltage Architecture (V) 12，14
Operating Temperature Range -40℃~120℃
Certification ISO9001, RoHS, REACH, TS16949



Overview

DTM series provide reliable waterproof connections for cable-to-cable applications across various environments, including engines, transmissions, chassis, under the hood, and within the cab.



Deutsch Features

✔ In line, flange, or PCB mount
✔ Multiple Pin Configurations:2.3,4.6,8 and 12 cavity
✔ High Current Capacity: 7.5A per contact with 20-gauge wires
✔ Easy Installation:reduced assembly time
✔ Environmental Seal:will handle extreme applications
