OEM Part Number |
HD16-9-1939S |
|
OEM Series |
HD10 |
|
MinMax Part Number |
1150000512 |
|
MinMax Family |
MCS083 |
|
Connection Type |
Wire to Wire |
|
Number of Positions |
9 |
|
Number of Rows |
|
|
Hybrid |
No |
|
Contact Tab Size (mm) |
/ |
|
Male/Female |
Black |
|
Sealable |
Yes |
|
Body Color |
Female |
|
Housing Material |
PA66 |
|
Nominal Voltage Architecture (V) |
12，14 |
|
Operating Temperature Range |
-40℃~120℃ |
The Deutsch HD10 Series is a compact, high-performance connector designed for space-constrained applications with strict reliability requirements. It is commonly used in control systems, sensor connections, and auxiliary equipment of heavy-duty vehicles, enabling stable connections in confined spaces such as around engines.
✔ Compact Design: Smaller form factor for space-constrained applications
✔ Pin Configurations: 2 to 12 cavity options
✔ Current Handling: Up to 13A per contact (with 16-gauge wires)
✔ Easy Installation: Tool-less assembly for reduced installation time
✔ Environmental Resistance: IP67 sealing, operable in -55°C to +125°C with resistance to fuels and lubricants
