OEM Part Number |
2428-004-2405 |
|
OEM Series |
DEUTSCH HDP |
|
MinMax Part Number |
/ |
|
MinMax Family |
/ |
|
Connection Type |
/ |
|
Number of Positions |
/ |
|
Number of Rows |
/ |
|
Hybrid |
No |
|
Contact Tab Size (mm) |
/ |
|
Male/Female |
/ |
|
Sealable |
No |
|
Body Color |
Black |
|
Housing Material |
PA 66 |
|
Nominal Voltage Architecture (V) |
/ |
|
Operating Temperature Range |
–55℃~125℃ |
|
Certification |
ISO9001, RoHS, REACH, TS16949 |
The Deutsch HDP Series is a heavy-duty connector engineered for high-power transmission, suitable for scenarios requiring high current output such as new energy vehicles, large generator sets, marine power systems, and industrial motors. It enables efficient and stable power transmission in extreme environments.
✔ High-Power Focus: Designed for high-current applications, up to 120A per contact (depending on model)
✔ Flexible Configurations: Various cavity counts and contact sizes (6mm to 16mm)
✔ Extreme Temperature Tolerance: Operates in -40°C to +150°C
✔ Heavy-Duty Sealing: IP6K9K rated to withstand high-pressure washing and harsh contaminants
✔ Secure Locking: Heavy-duty bayonet locking system for vibration resistance and reliable connection
On the Engine
On the transmission
Automotive Under the Hood
On the Chassis
In the Cab
in the heavy duty
EDM Mirror Processing
EDM Parts
Slow-feeding wire cut machine
CNC Machine
Plastic Injection Machine
Automatic production Line
Step 1 Crimp the terminal and do the pull-out test to make sure the crimpings are completed
step 2 Crimping terminal and matched connector
Step 3 Insert the terminal to the connectors
Step 4 finished the connecting.
